Send InquiryMaruti Rope Coiling Machines MP/CL - 1434
Price 351000.0 INR/ Unit
Maruti Rope Coiling Machines MP/CL - 1434 Specification
- Product Type
- Rope Coiling Machine
- General Use
- Rope coiling for 12-32MM ropes
- Material
- Other
- Type
- Other
- Weight (kg)
- 430 Kilograms (kg)
- Computerized
- No
- Automatic
- Yes
- Control System
- Auto Adjustable Traverse
- Power Source
- Electric
- Power Consumption
- 3.7 Kilowatt (kW)
- Coil Diameter
- 26 Millimeter (mm)
- Winding Speed
- 150 RPM miles/hr (MPH)
- Winding Spindle
- 1
- Voltage
- 220 Volt (v)
- Dimension (L*W*H)
- 10.6 X 5.1 X 4.0 Foot (ft)
- Feature
- High Precision, Low Energy Consumption, High Speed
- Color
- Black/Metallic
- Coil Weight
- 25 Kg max
- Steel frame design
- Yes
- Single workstation
- Yes
- Heavy-duty construction
- Yes
- Rope Size
- 4 to 12 mm
- Model
- MT CL / 412
Maruti Rope Coiling Machines MP/CL - 1434 Trade Information
- Minimum Order Quantity
- 1 Unit
- Payment Terms
- Cash in Advance (CID)
- Supply Ability
- 100 Units Per Month
- Delivery Time
- 90 Days
- Main Export Market(s)
- Western Europe, Middle East, Asia, Australia, South America, Eastern Europe, Africa, Central America, North America
- Main Domestic Market
- All India
About Maruti Rope Coiling Machines MP/CL - 1434
14-34mm Rope Coiling Machines Key Features:- Digital length counter meter is used
- Machine operation is easy
- Winding is done layer by layer, uniformly
- The traverse system is self-adjustable
- Coil finishing is excellent
- For the purpose of making coils, many models are available
- For pay off bobbin, a mechanical brake system is used
Optional Features:
- Coil-to-recoil mechanism is used
- AC frequency drive is used
- To remove the final package, an electric wire hoist is used
| Automation Grade | Automatic |
| Frequency | 50 Hz |
| Voltage | 220 V |
| Weight | 750 Kg |
| Motor Capacity | 3.7 Kw |
| Country of Origin | Made in India |
| Model Name/Number | MP/CL - 1232 |
| Rope Size | 26mm |
| Coil Weight | 110 Kg |
| Head Speed | 150 RPM |
| Brand | Maruti Plastotech |
| Production Capacity | 428 Kg/Hr |
